OV9734 Key Specifications (typical)
2023/03/21
active array size: 1280 x 720
power supply:
analog: 2.6 ~ 3.0V (2.8V normal)core: 1.2VDC土5%
VO: 1.8V
power requirements:
active: 69 mW
XSHUTDN: 0.9 uW
temperature range
operating: -30°C to 85°C junction temperature
stable image: 0°C to 50°C iunction temperature
output formats: 10-bit Raw RGB
lens size: 1/9"
lens chief ray angle: 32.1° input clock frequency: 6 ~ 27 MHz scan mode: progressivemaximum image sensitivity: 585 mV/Lux-secshutter: rolling shuttermax S/N ratio: 36.4 dBdynamic range: 68.4 dB @ 16x gainmaximum exposure interval: 798 x tRow
pixel size: 1.4 um x 1.4 um
dark current: 2e/sec @ 50°C junction temperature
image area: 1819.58 um x 1033.34 um
package dimensions: 2532 x 1722 um
